Product name: TPF-9SF hydraulic balanced double column lift

Recommended unit: Shanghai Xianghong Automobile Maintenance Equipment Co., Ltd.

① Brand-new concept hydraulic double-column lift, leading hydraulic balance technology;

②The S-shaped section design of the column greatly enhances the overall strength of the equipment;

③The core hydraulic system (cylinder, power unit) is specially supplied by United Hydraulics;

④The height and the width between the main bodies can be adjusted according to the needs of the site;

⑤There is no floor connection, which is convenient for vehicles to enter and exit, breaking through the traditional physical connection;

⑥Asymmetrical installation, which provides enough space for opening the door, suitable for more models

⑦The self-locking mechanism of rocker arm and sliding table enhances the safety of equipment use;

⑧The column is positioned separately, the installation is simple and fast, and the work efficiency is greatly improved.

Detailed parameter description:

Machine model: TPF-9SF/TPF-10SF

Drive mode: electro-hydraulic

Rated lifting weight: 4T/4.5T

Maximum lifting height: 1990mm

Minimum height: 90mm

Total height: 3650mm

Width between columns: 2860mm

Passing width: 2560mm

Lifting time: ≤50mm

Machine description:

The "Liberty" hydraulic balance double-column lift TPF-9SF/10SF utilizes leading hydraulic balance technology to control the synchronization of hydraulic cylinders. The oil pressure of the hydraulic cylinder during each complete lifting process is regulated and controlled. In this way, there is no need to replenish hydraulic oil as usual for a long time, and a good synchronization can be guaranteed. The SF series brings more safety, ensuring that the hydraulic cylinders of these lifting vehicles are 100% synchronized and completely level. Traditional hydraulic lifts may cause unevenness of the lifts due to years of disrepair, while the SF series will not happen at all. SF series no longer need to add hydraulic oil and adjust the platform level regularly. SF means less wear and tear. After adopting hydraulic balancing technology, the wire rope to ensure synchronization is no longer needed. The moving parts of the lift are also reduced. On the one hand, it reduces the use of redundant wearing parts. On the other hand, it makes the height and width of the lift more flexible. "Lady Liberty" makes daily maintenance work for customers simple and effective. The lift can ensure synchronization and no need for ropes. The two-post lift no longer needs to be installed accurately to the centimeter. It can be installed according to the site conditions without worrying about obstacles in the workshop. The installation position can be placed freely. An installer completed the installation of the lift, which greatly increased the efficiency of the installation.
